Because C-Lasky supplies high concentrated ozone, it is suitable for instantaneous air cleanness or setting the timer for large space air disinfecting and dispelling insects at night. It has been widely applied to air clearness, goods reservation and bacteria disinfection in places such as office, library, hospital, hotel room, warehouse, supermarket, restaurant and food industry.

When used for air treatment, C-L010 is capable of producing 150 cubic meters per minute of ozonated air at 0.05 ppm air concentration. The concentration may be increased up to 0.25 ppm if an external oxygen gas supply is used. When applied to a large area, it is recommend that ozone is dispersed via 15 holes (1 mm in diameter) along a 1/4" O.D Teflon tube. All of them can be easily added into various systems depending on the request of ozone concentration and ozone production.

1.

A space of dimension 16 m², height 3.5 m requires a period of 1 minute process.

2.

One hour later after switching off the generator, if the ozone is still residual in the room, it implies operating period must be cut down.

3.

While people present in the venue, the ozone concentration must remain below 0.05 ppm (with light smell of grass), nevertheless, cannot expose over 8 hours per day. By law, for maximum human exposure is set at 0.1 ppm (smell tangy odor) for a cumulativeeight-hour period per day.

4.

For several rooms or huge space applications, a 1/4" Teflon tube with maximum 15 holes (1 mm in diameter) is needed for diffusing ozone well.

1.

Install a check vale to the outlet of ozone output and be sure the Teflon tube that conducts the ozone gas has to be higher than the water level to prevent the water back stream.

2.

Using an external oxygen concentrator to increase ozone production.
